• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Belt Section	A
Type	Super Gripbelt V-Belts
Pitch Length	93.3
Height	0.3125
Material	Neoprene
Width (in)	0.5 in
Product Type	Wrapped Belt
Efficiency (%)	0.95
Operating Temperature [Max] ºF	140 °F
Outside Diameter (in)	94.22 in
Operating Temperature [Max] ºC	60 °C
Outside Length/Diameter (in)	94.22 in
Belt Series	Gripbelt
Construction Type	Classic
Section Size	A

General Specifications

UPC	662289128648
Weight	0.69 LB
Packaged Length	5.80 IN
Packaged Width	13.60 IN
Packaged Height	1.55 IN
HTC	4010.34.3000
Country of Origin	Romania
