• 90% Efficiency-Up to 2x Torque
• Four sizes can replace up to twelve sizes of worm speed reducers
• Cast iron housing
• Rolling action gearing (helical and hypoid)
• Over-sized bearings
• Viton® seals
• Bronze bushing quill liner
• Factory lubricated with Food Grade synthetic lubricant - USDA H1
• HubLoc® keyless bushing system is available on hollow output bore HERA gear drives.

Technical Specifications

Output RPM	112.2
Input Diameter (in)	0.749 in
Input HP	2.18
Style	AS
Product Line	HERA
Service Factor	1
Output Diameter (in)	1.000 in
Ratio	15.60:1
Product Type	RIGHT ANGLE
Series Code	HERA35
Input HP @ 1750 RPM	2.18
Input Style	Shaft
Mounting Type	AS
Housing Length (in)	7.19 in
Reduction	Double
Housing Height (in)	5.75 in
Housing Width (in)	5.5 in
Length Through Bore (in)	5.5 in
Housing Material	Cast iron
Output Torque Range (in-lb)	1000 to 2500 in lbs in/lbs
Output Torque Rating (in-lb)	1100 in/lbs
Center Distance (in)	2.509 in
Nominal Ratio	15:1
Gear Drive SIze	HERA35
Housing Dimensions (in)	(L)7.19 x (H)5.75 x (W)5.5 in
Output Shaft	Hollow Bore

General Specifications

UPC	662798808819
Weight	30.00 LB
Packaged Length	12.00 IN
Packaged Width	10.00 IN
Packaged Height	11.00 IN
