Роликовая направляющая из углеродистой стали Bosch Rexroth RSA-065-SNS-U-MA-0T [R180562935]
Описание
Roller guide rail, SNS, size 65, steel CS, accuracy ultra precision
Product Description
The roller guide rail is highly precise and characterized by the following product features:
Size 65
Format SNS: Width = slimline, length = normal, height = standard
Guide rail made of carbon steel CS
Fastener MA: Bolting from above
Cover OT: Without cover, with end-face thread
Accuracy class ultra precision
Number of partial sections: one-piece
Rail in standard version
Technical Specs
Характеристики
| Характеристики изделия | |
| Version | Roller rail systems |
| Nominal size [mm] | 65 |
| Format | SNS - Standard guide rail |
| Material (profiled rail systems) | Carbon steel |
| Accuracy class | UP - Ultra precise |
| Guide rail mounting | For bolting from above |
| Guide rail cover | Without cover strip |
| Max. length Lmax [mm] | 3971 |
| Minimum length Lmin [mm] | 192 |
| Number of holes nB (profiled rail systems) | 53 |
| Number of sections | 5-piece |
| Mass m (kg/m) [kg/m] | 17.4 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Note: permissible ambient temperature (min. ... max.) | 100°C admissible for a short time. For operation at lower minus temperatures, please consult us. |
| Масса (кг) | 0 |
| Recommended rail length (formula) | L = nB • T ‒ 4 mm |
| Product information | Available on request |
| Pitch T guide rail [mm] | 75 |
| Dimension A2 (profiled rail systems) [mm] | 63 |
| Dimension D [mm] | 26 |
| Dimension diameter S5 (profiled rail systems) | 18 |
| Dimension H2 without cover strip (profiled rail systems) [mm] | 57.85 |
| Dimension N6 (profiled rail systems) [mm] | 36.5 |
| Dimension N6 tolerance (profiled rail systems) [mm] | ±0.5 |
| Dimension N7 (profiled rail systems) [mm] | 40 |
| Dimension T [mm] | 75 |
| Dimension T1 max (profiled rail systems) [mm] | 55 |
| Dimension T1 min [mm] | 21 |
| Dimension T1 s (profiled rail systems) [mm] | 35.5 |
| Footnote of dimension T1 s (profiled rail systems) | Preferred dimension T1S with tolerances ±0.75 |
