Роликовая направляющая устойчивая к коррозии с покрытием Resist CR Bosch Rexroth RSA-025-SNS-H-MA-SK [R184620344]
Описание
Roller guide rail, SNS, size 25, Resist CR \u2013 coating, accuracy high
Product Description
The roller guide rail is highly precise and corrosion-resistant thanks to its Resist CR coating. Additionally, it is characterized by the following product features:
Size 25
Format SNS: Width = slimline, length = normal, height = standard
Guide rail made of carbon steel CS, matte-silver, hard chrome plated
Fastener MA: Bolting from above
Cover SK: Steel caps (must be ordered separately)
Accuracy class high
Number of partial sections: one-piece
Rail in standard version
Technical Specs
Характеристики
| Характеристики изделия | |
| Version | Roller rail systems |
| Nominal size [mm] | 25 |
| Format | SNS - Standard guide rail |
| Material (profiled rail systems) | Hard chrome plated |
| Accuracy class | H - Highly accurate |
| Guide rail mounting | For bolting from above |
| Guide rail cover | With steel caps |
| Max. length Lmax [mm] | 3986 |
| Minimum length Lmin [mm] | 86 |
| Number of holes nB (profiled rail systems) | 133 |
| Number of sections | 4-piece |
| Mass m (kg/m) [kg/m] | 3.1 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Note: permissible ambient temperature (min. ... max.) | 100°C admissible for a short time. For operation at lower minus temperatures, please consult us. |
| Масса (кг) | 0 |
| Recommended rail length (formula) | L = nB • T ‒ 4 mm |
| Pitch T guide rail [mm] | 30 |
| Dimension A2 (profiled rail systems) [mm] | 23 |
| Dimension D [mm] | 11 |
| Dimension D1 [mm] | 12.55 |
| Dimension D2 [mm] | 13 |
| Dimension diameter S5 (profiled rail systems) | 7 |
| Dimension H2 without cover strip (profiled rail systems) [mm] | 23.4 |
| Dimension N10 (profiled rail systems) [mm] | 3.7 |
| Dimension N11 (profiled rail systems) [mm] | 0.9 |
| Dimension N6 (profiled rail systems) [mm] | 14.3 |
| Dimension N6 tolerance (profiled rail systems) [mm] | ±0.5 |
| Dimension T [mm] | 30 |
| Dimension T1 max (profiled rail systems) [mm] | 20 |
| Dimension T1 min [mm] | 10 |
| Dimension T1 s (profiled rail systems) [mm] | 13 |
| Footnote of dimension T1 s (profiled rail systems) | Preferred dimension T1S with tolerances ±0.75 |
