• Through hardened bearing grade steel
• Surfaces precision ground to RBEC 1 tolerances
• Crowned rollers

Dimensions

Overall Width (mm)	43 mm
Bore Size (mm)	55 mm
Outside Diameter (mm)	120 mm

Technical Specifications

Version	EM: Extra capacity design; Machined brass retainer
Inner Race Configuration	Separable Both Directions
Outer Race Configuration	Non-Separable
Additional Information	Suitable for radial loads only
Cage Material	Brass
Seal Type	Unsealed
Static Load Rating (kN)	213 kN
Bore Type	Straight
Radial Clearance	C3
Number of Rows	1
Rolling Element	Cylindrical Roller
Material	High Chromium Bearing Steel
Misalignment	No
Full Complement/Caged	Caged
Sealed	None
Speed [Max] Oil (RPM)	5,600 rpm
Duplexing	No
Dynamic Load Rating (lb)	42,107 lb
Platform	Cylindrical Radial
Speed [Max] Grease (RPM)	4,800 rpm
Static Load Rating (lb)	47,884 lb
Snap Ring	No
Retainer	Yes
Separable	Inner ring - both sides
Profile	Complete with Outer and Inner Race

General Specifications

UPC	637410087514
Weight	4.96 LB
Packaged Length	4.72 IN
Packaged Width	1.69 IN
Packaged Height	4.72 IN
Country of Origin	China
