AL Type Hubs with Keyway - Metric Bores Timken 68514447427

Name: AL Type Hubs with Keyway - Metric Bores Timken 68514447427
Brand: TIMKEN
SKU: 68514447427
Availability: PreOrder

Артикул:68514447427

Категория:Муфты

Цена по запросу

Под заказ

Узнать цену и наличие

Весь товар сертифицирован

Доставка по Беларуси и СНГ

Скидки постоянным клиентам

Работаем с юр. лицами и ИП

Описание

The AL Type coupling consists of two standard AL Type hubs and one spider (find under L Type components, or the AL section for AL150).Unless stated otherwise, hub torque and horsepower ratings assume a SOX(NBR) rubber spider is being used.

Notes

Характеристики

Notes	Lovejoy does not recommend reboring AL hubs.
Характеристики
Description	AL075-HUB-19MMH7-6X2.8MMKW
Hub Style	2
Coupling Type	Jaw
Материал	Aluminum
Color	Silver
# of Jaws	3
Elastomeric Member	SOX (NBR) Rubber
Масса	73 г
Weight - Solid	136 г
Weight (Complete Coupling w/ Max. Bores)	181 г
Dimensional Data
Диаметр отверстия	19.00 mm
Coupling Size	AL075
Keyway Size (W x D)	6 x 2.8
Length thru Bore	0.810 in
Общая длина	2.12 in
Min. Bore (Dimensions ID1/ID2)	0.250 in
Max. Bore (Dimensions ID1/ID2)	0.875 in
Hub Length	1.310 in
Dimension G	0.5 in
Наружный диаметр	1.530 in
Dimension SL	.31 in
Cubic inches	4.01188 in³
Performance Data
Nominal Torque	90.00 in·lb
Max. Speed	11000.00 об/мин
Moment of Inertia (Solid) WR2	0.121 lb·in²
Rated HP at 100 rpm	.14 hp
Rated HP at 1,200 rpm	1.68 hp
Rated HP at 1,800 rpm	2.57 hp
Rated HP at 3,600 rpm	5.04 hp
Spider Performance
Spider Performance	Nitrile Butadiene (Buna N) Rubber is a flexible elastomer material that is oil resistant, resembles natural rubber in resilience and elasticity and operates effectively in temperature range of -40° to 212° F (-40° to 100° C). Good resistance to oil. Standard elastomer. (Also applies to SXB Cushions.)
Features
Features	Interchangeable with all hub sizes standard for the L-Line and AL-Line products
