AL Type Hubs with Keyway - Metric Bores Timken 68514458620

Name: AL Type Hubs with Keyway - Metric Bores Timken 68514458620
Brand: TIMKEN
SKU: 68514458620
Availability: PreOrder

Артикул:68514458620

Категория:Муфты

Цена по запросу

Под заказ

Узнать цену и наличие

Весь товар сертифицирован

Доставка по Беларуси и СНГ

Скидки постоянным клиентам

Работаем с юр. лицами и ИП

Описание

The AL Type coupling consists of two standard AL Type hubs and one spider (find under L Type components, or the AL section for AL150).Unless stated otherwise, hub torque and horsepower ratings assume a SOX(NBR) rubber spider is being used.

Notes

Характеристики

Notes	Lovejoy does not recommend reboring AL hubs.
Характеристики
Description	AL090-HUB-11MMH7-4X1.8MMKW
Hub Style	2
Coupling Type	Jaw
Материал	Aluminum
Color	Silver
# of Jaws	3
Elastomeric Member	SOX (NBR) Rubber
Масса	113 г
Weight - Solid	181 г
Weight (Complete Coupling w/ Max. Bores)	227 г
Dimensional Data
Диаметр отверстия	11.00 mm
Coupling Size	AL090
Keyway Size (W x D)	4 x 1.8
Length thru Bore	0.910 in
Общая длина	2.340 in
Min. Bore (Dimensions ID1/ID2)	0.250 in
Max. Bore (Dimensions ID1/ID2)	0.875 in
Hub Length	1.430 in
Dimension G	0.52 in
Наружный диаметр	1.530 in
Dimension SL	0.340 in
Cubic inches	6.42699 in³
Performance Data
Nominal Torque	144 in·lb
Max. Speed	9000.00 об/мин
Moment of Inertia (Solid) WR2	0.271 lb·in²
Rated HP at 100 rpm	0.23 hp
Rated HP at 1,200 rpm	2.76 hp
Rated HP at 1,800 rpm	4.11 hp
Rated HP at 3,600 rpm	8.28 hp
Spider Performance
Spider Performance	Nitrile Butadiene (Buna N) Rubber is a flexible elastomer material that is oil resistant, resembles natural rubber in resilience and elasticity and operates effectively in temperature range of -40° to 212° F (-40° to 100° C). Good resistance to oil. Standard elastomer. (Also applies to SXB Cushions.)
Features
Features	Interchangeable with all hub sizes standard for the L-Line and AL-Line products
