• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	3/8 to 1
Number of teeth	14
Product Type	Gearbelt Pulley
Width (mm)	38.1 mm
Bore Type	Bushed Bore
Material	Steel
Pitch Diameter (in)	2.228 in
Outside Diameter (in)	2.174 in
Flange (in)	2.477 in
Outside Diameter (mm)	55.2196 mm
Belt Section	H
Width (in)	1.5 in
Face Width	1.8125
Hub Diameter (in)	2 in
Pulley Construction	Solid
Length Through Bore	1
Hub Projection	0.73525
Overall Length (in)	2.54725 in
Number of Hubs	1
With Flanges	With Flanges

General Specifications

UPC	662289263912
Weight	1.26 LB
Packaged Length	2.56 IN
Packaged Width	2.56 IN
Packaged Height	1.94 IN
HTC	8483.50.9080
Country of Origin	United States of America
