• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	50.8 mm
Number of teeth	40
Bore Range	3/4 to 2 11/16
Product Type	Gearbelt Pulley
Model Name	GBPulley_Master5
Bore Type	Bushed Bore
Material	Ductile Iron
Outside Diameter (in)	6.312 in
Belt Section	H
Width (in)	2 in
Flange (in)	6.6000 in
Pitch Diameter (in)	6.366 in
Inside Diameter (in)	4.8125 in
Outside Diameter (mm)	160.3248 mm
Face Width	2.2813
Pulley Construction	Solid
Overall Length (in)	2.78125 in
Number of Hubs	1
Hub Projection	0.40625
Length Through Bore	2.5
Hub Diameter (in)	4.125 in
With Flanges	With Flanges

General Specifications

UPC	662289114153
Weight	12.94 LB
Packaged Length	8.00 IN
Packaged Width	8.00 IN
Packaged Height	5.00 IN
HTC	8483.50.9080
Country of Origin	United States of America
