• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Pitch Length	34.3
Belt Section	A
Type	Super Gripbelt V-Belts
Height	0.3125
Material	Neoprene
Efficiency (%)	0.95
Operating Temperature [Max] ºC	60 °C
Outside Length/Diameter (in)	35.22 in
Product Type	Wrapped Belt
Width (in)	0.5 in
Outside Diameter (in)	35.22 in
Operating Temperature [Max] ºF	140 °F
Standards met	MPTA IP-20;RMA
Section Size	A
Band Type	Belt with Ends Joined
Belt Series	Gripbelt
Construction Type	Classic
Reinforcing cord material	Synthetic Fiber

General Specifications

UPC	662289168071
Weight	0.25 LB
Packaged Length	4.20 IN
Packaged Width	15.25 IN
Packaged Height	1.10 IN
HTC	4010.32.3000
Country of Origin	Mexico
