• No Maintenance Needed: The latest TorqTitan™ V-Belts need no re-tensioning or maintenance after installation.
• Increased Power: With 30% more horsepower, they enable smaller, cost-effective drive designs.
• Durable Material: Constructed from EPDM material, they operate reliably in temperatures from -40°F to 248°F.
• Precision Matching: The "Code 1" Match belt system exceeds RMA* standards, minimizing vibration and noise.
• Enhanced Grip: Raw-edge sidewalls enhance grip for smoother, quieter performance.
• <i>*RMA = Rubber Manufacturers Association</i>

Technical Specifications

Belt Section	BX
Pitch Length	38.8
Type	TorqTitan Notched V-Belts
Material	EPDM
Product Type	Notched Belt
Operating Temperature [Max] ºF	251 °F
Outside Diameter (in)	40 in
Efficiency (%)	0.98
Operating Temperature [Max] ºC	120 °C
Outside Length/Diameter (in)	40 in
Belt Series	TorqTitan
Standards met	ARPM IP-20
Construction Type	Cogged
Number of Ribs	1
Section Size	BX
Width (in)	0.65 in
Reinforcing cord material	Polyester
Height	0.44
Operating Temperature Range	-40 to +251 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ISO1813

General Specifications

UPC	662460415062
Weight	0.35 LB
Packaged Length	17.40 IN
Packaged Width	4.35 IN
Packaged Height	0.80 IN
HTC	4010.32.3000
Country of Origin	Romania
