• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bushing Type	Q2
Model Name	Q2-Type1_Bushing_Master
Length Through Bore (in)	3.5 in
Compatible Bore Size [Max] (in)	1.1875 in
Total Length (in)	3.5 in
Keyseat	1/4 x 1/8
Material	Sintered Steel or Ductile Iron
Outside Diameter (in)	4.125 in
Product Type	Split Taper Bushing
Wrench Torque (in-lb)	348
Bore Size (in)	1.1875 in
Cap Screws (Size)	3/8 x 1 1/4
Cap Screws (No.)	3
Bore Type	Inch
Mounting Type	Conventional
Flange Type	Solid Flange
Screw Length	1.25
Thread Size	3/8-16
Barrel Diameter (Large End)	2.875
Includes	Cap Screws and Ext. Key
Flange Thickness	0.5
Barrel Diameter (Small End)	2.7032
Bolt Circle Diameter (in)	3.375

General Specifications

UPC	662289129935
Weight	5.52 LB
Packaged Length	4.30 IN
Packaged Width	4.60 IN
Packaged Height	3.70 IN
HTC	8483.90.8080
Country of Origin	Mexico
