• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bushing Type	SD
Model Name	QD-SD_Bushing_Master
Product Type	Q-D Bushing
Torque Capacity (in-lb)	5,000
Outside Diameter (in)	3.125 in
Total Length (in)	1.83 in
Keyway	1/4 x 1/8
Cap Screws (Bolt Circle)	2.6875
Length Through Bore (in)	1.83 in
Cap Screws (No.)	3
Mounting Type	Conventional
Compatible Bore Size [Max] (in)	1.125 in
Wrench Torque (ft.-lbs.)	9
Cap Screws (Size)	1/4-20 x 1 7/8
Bore Type	Inch
Bore Size (in)	1.125 in
Barrel Length	1.38 in
Flange Thickness	0.45 in
Material	Ductile Iron - 65-45-15
Barrel Diameter	2.1875 in

General Specifications

UPC	662289344604
Weight	1.75 LB
Packaged Length	4.06 IN
Packaged Width	4.06 IN
Packaged Height	1.88 IN
