Роликовая каретка из углеродистой стали Bosch Rexroth RWA-125-FLS-C2-P-2 [R186332210]

Roller runner block, FLS, size 125, steel CS, accuracy precision, average preload

Product Description

The roller runner block is highly precise and characterized by the following product features:
Size 125
Format FLS: Width = flange, length = long, height = standard
Runner block body made of unalloyed steel CS
Preload class C2: Medium preload
Accuracy class P: Precision
Without roller chain
Preserved
Without initial lubrication
Without attachment element, left (front reference edge)
Without attachment element, right (front reference edge)
Straight lube connection loosely attached.
Runner block body in standard version
Overall length of the runner block = 491.5 mm
Interchangeability: The runner block and the guide rails can be combined with each other with every accuracy.

Heavy-Duty Roller Runner Block for heavy machine construction with extremely high load capacityMaximum rigidity in all load directionsImproved rigidity under lift-off and side loading conditions due to three additional mounting screw holes at the center of the Roller Runner BlockHigh torque load capacityLimitless interchangeability and any number of combination options thanks to uniform Roller Guide Rails in different versions across all Roller Runner Block variantsAttachments on the Roller Runner Block can be mounted from above and belowLube nipples possible on all sides for easy maintenanceMinimum lubrication quantities thanks to innovative channel designSmooth, quiet running thanks to optimally designed return and guideways of the rollersMinimal variation in elastic deflection thanks to optimized entry-zone geometry and high number of rollersAluminum end caps (size 125) and\/or plastic (size 100)Integrated front seals are included as standard for improved sealing of all running tracks and to protect the plastic parts
